ReDOX FT Low Profile: DIY Mechanical Keyboard Kit

Redox FT Low Profile DIY Kit – Build Your Own Ultra-Slim Ergonomic Keyboard by FalbaTech

The Redox FT Low Profile DIY Kit is for builders who want to assemble the thinnest, most ergonomic version of the iconic Redox.

With a total height of just 16 mm, compatibility with Kailh Choc v1 low-profile switches, and multiple handcrafted case options, this kit delivers a modern, minimal, highly customizable typing experience.

All parts are matched, organized, and ready for self-assembly and soldering.

Ultra-Low Profile Construction

• Total height: 16 mm from desk to top of keycap
• Standard Redox height: ~34 mm (for comparison)
• Slim design reduces wrist strain and improves long-term comfort
• Low front edge eliminates the need for wrist rests unless you prefer them

Hotswap-Ready PCBs

Designed for Kailh Choc v1 low-profile switches (not included).

Hotswap sockets allow switch changes without soldering.

Switch Compatibility – Kailh Choc v1

Recommended options:

Kailh Choc Red

• Linear feel
• 50 g actuation
• 1.2 mm actuation point
• 3.2 mm travel

Kailh Choc Brown

• Tactile bump
• 55 g actuation
• 1.5 mm actuation point
• 3.2 mm travel

Other Choc v1 variants available on request (lead time may increase).

Case Designs

Choose the body you want to assemble:

Standard

Classic frame without wrist rests

FullHand Ver.1

Flat integrated wrist rest

FullHand Ver.2

Rounded wrist rest for more ergonomic support

Joined (Butterfly)

Both halves permanently connected into one compact case

Materials & Finishes

Bamboo

Lightweight, eco-friendly, CNC-machined

Beech Wood

Durable hardwood, hand-finished with protective 3V3 oil

PETG Geometric Shimmer™

3D-printed from recycled black PETG, carbon-weave-like texture, modern technical aesthetic

Finish options:

• Natural 3V3 countertop oil
• Dark stain + oil
• Matte black eco paint (child-safe, toy-grade)

Dimensions & Weight

• Size per half: 179.4 × 143.5 × 16 mm
• Weight per half: around 440 g
• Optional tilt/tent kit for ergonomic angle adjustment

Accessories & Add-Ons

oriBag™ Felt Sleeve

Black or grey, tailored for Redox FT (including Joined version)

Desk Felt Mat (4 mm PET felt)

Black or grey, soft, durable, and eco-friendly

SlimXDA™ Keycaps (optional)

Low-profile PETG keycaps, DSA-height with XDA geometry

Available in natural colors or custom shades upon request

Sustainability & Craftsmanship

• Switch plates for low-profile versions are 3D-printed from recycled PETG
• All cases are CNC-machined and finished by hand in our Polish workshop
• Natural wood may show small variations — part of authentic artisan work
• Materials and switches sourced primarily from the EU

Important

This is a DIY soldering kit. Assembly and soldering are performed at your own responsibility.

The kit includes components only — not an assembled keyboard.
